Aliphatic Amines

Aliphatic amines are usually fast curing, low viscosity, and good chemical resistance to the applied system. However, it is usually modified to eliminate problems caused by objectionable volatility of such amines. By pre-reacting the amine with part of the epoxy resin formed Polyamine Adduct. The adduct polyamine reduced blushing tendency during cure of films, reduced toxicity and volatility. When modified it has wide range of products with differing properties. The aliphatic polyamine cured system are resistant to attack by alkalies, solvents and some inorganic acids; they are less resistant to most organic acids.

General Performance

  • Low viscosity
  • Developed to improve certain characteristics such as pot life, faster cures and easier handling
  • Excellent cured resin physical characteristics including chemical and solvent resistance.
  • Good long term retention of properties
  • Short term exposure at high temperature can be tolerated
  • Excellent resistance to aqueous alkali
  • Strong organic acids such as acetic acids not recommended
  • Solvent resistance is good
  • Low hygroscopicity
Products Amine Value
(mg KOH/g)		 Viscosity
(25°C, cPs) 1)		 Color
(Gardner)		 Pot life
(mins) 2)		 AHEW Type Properties / Applications

Jointmine

238

320 ± 20

30 ~ 100

<3

90

83

Modified Aliphatic Amine

Long Pot life, free amine blush, good color stability, low exudation. Decoupage, flooring applications, hand lay-up laminating, tooling, solvent free coatings

Jointmine

2383E

330 ± 20

50 ~ 100

<3

90 ~ 100

80

Modified Polyamine

Industrial flooring, concrete repair mortar, high-build coatings

Jointmine

2383K

350 ± 20

30 ~ 80

<3

35 ~ 45

80

Modified Polyamine

Industrial flooring, concrete repair mortar, high-build coatings

Jointmine

2383EK

330 ± 20

50 ~ 100

<3

60 ~ 70

80

Modified Polyamine

Industrial flooring, concrete repair mortar, high-build coatings

Jointmine

240

360 ± 20

400 ~ 1,000

<5

37

95

Polyamine Adduct

Low cost floor coating, solvent-free coating, high build coating. Benzyl Alcohol free.

Jointmine

241-1

350 ± 20

100 ~ 300

<5

53

85

Polyamine Adduct

Low viscosity, good adhesive strength, cures in thin section. Hand lay-up laminating, solvent-free coating, high build coating.

Jointmine

9522

365

207

1

51 *3

85

Polyamine Adduct

Cure in thin section, low viscosity, non-amine blushing. Solvent-free primer, hand lay-up laminating & tooling, decorative industrial flooring.

Jointmine

9522-1

310 ± 20

200 ~ 500

<5

20 ~ 30

@145g

85

Modified Aliphatic Amine

Solvent-free primer, hand lay-up laminating & tooling, decorative industrial flooring.

Jointmine

930

450 ± 20

10 ~ 30

<2

300

65

Aliphatic Amine

Low viscosity, low color, low vapor pressure. Electrical casting, solvent free coatings, impregnations and flooring

Jointmine

9403

530 ± 30

20 ~ 100

<5

30 ~ 40

50

Aliphatic Amine Adduct

Low viscosity, high mechanical properties. Injection systems, repair mortars, pourable grout.

Jointmine

401

510 ± 20

300 ~ 600

<2

25

52

Modified Aliphatic Amine

Light color, low viscosity, less amine blush. Adhesives, pipe coating, secondary containment, tank linings and encapsulation

Jointmine

402

260 ± 20

8,000 ~ 15,000

<2

8 ~ 9

180

Aliphatic Amine Adduct

Transparent, fast cure. Fast curing adhesives, waterproofing sealer, pipe joint sealing

Jointmine

4021

240 ± 20

6,500 ~ 13,000

<3

5 ~ 10

198

Aliphatic Amine Adduct

Resistance to acids and solvents, good adhesion to concrete & steel, high flexibility. Fast curing adhesives, waterproofing sealer, pipe joint sealing

Jointmine

4022

180 ± 20

6,500 ~ 13,000

<3

2 ~ 3

207

Modified Polyamine

Excellent physical properties, improved moisture resistance, rapid cure, thin film cure, light color, fast curing adhesives at low temperature. Cold weather construction adhesives, emergency leaks repair

Jointmine

840-3

610 ± 20

100 ~ 200

<3

22

60

Aliphatic Amine Adduct

Low viscosity, chemical resistance, good heat resistance. Chemical tank coatings, heat-resistant coatings

Jointmine

840-5

430 ± 20

300 ~ 800

<3

35

95

Aliphatic Amine Adduct

Good heat resistance. Chemical tank coatings, heat-resistant coatings

Jointmine

900

540 ± 20

150 ~ 350

<6

5 ~ 10

57

Mannich Base

Fast curing at low temperature, low viscosity, high HDT. Cold weather coatings applications, repair mortars, chemical resistant coatings

Jointmine

900C

360 ± 20

500 ~ 1,000

<8

11

90

Mannich Base

Rapid cure at low temperature & humid condition, good flexibility & adhesion properties. Floor topping compounds, repair mortars, chemical tank linings
Products Amine Value
(mg KOH/g)		 Viscosity
(25°C, cPs) 1)		 Color
(Gardner)		 Pot life
(mins) 2)		 AHEW Type Properties / Applications

Jointmine

910

400 ± 20

800 ~ 1,300

<11

11

100

Modified Polyamine

Rapid development of physical properties, cures in damp condition. Damp concrete bonding, repair work on wet weather, underground repair work

Jointmine

910BS

340 ± 20

600 ~ 1,000

<11

32

100

Modified Polyamine

Damp concrete bonding, repair work on wet weather, underground repair work

Jointmine

913

660 ± 20

800 ~ 1,500

<8

7

65

Mannich Base

High strength concrete adhesives, fast cure & high toughness. Anchoring, pile splicing, machine grout, repair mortar, damp surface concrete adhesives

Jointmine

913-4

660 ± 20

800 ~ 1,500

<8

7

50

Mannich Base

High strength, high toughness, fast cure, low temperature cure. Anchoring, pile splicing, machine grout, repair mortar, damp surface concrete adhesives

Jointmine

913-3

600 ± 25

1,500 ~ 3,500

<7

3.5

@200g

95

Mannich Base

Accelerator, fast-set adhesive, fast-set concrete bonding & patching compound.

Jointmine

914

640 ± 30

600 ~ 1,200

<6

16

50

Mannich Base

High strength concrete adhesives, anchor bolt adhesive, repair compound, high solid coatings

Jointmine

914H

630 ± 30

2,500 ~ 5,500

<6

17

54

Mannich Base

High strength concrete adhesives, anchor bolt adhesive, epoxy mortar & concrete repair

Jointmine

9472

780 ± 30

1,000 ~ 3,000

<10

12 *3

50

Mannich Base

Fast thin film set time at low temperature & high humidity conditions. Adhesives, laminates, concrete repair & mortars.

Jointmine

P-117

450 ± 30

80,000 ~ 160,000

<11

15 ~ 20

97

Mannich Base

Underwater or wet surface cure epoxy putties, bonding agents

Jointmine

292

360 ± 20

3,000 ~ 9,000

<8

55 *3

95

Mannich Base

Chemical tank lining, secondary containment coatings, skydrol resistance coatings.

Jointmine

9204-1

570 ± 20

2500 ~ 4000

<8

10 ~ 20

68

Mannich Base

Good thin film cure, solvent & chemical resistant. Flooring compounds, ship deck coatings.

Jointmine

9130

800 ± 50

20 ~ 50

<7

45

35

Polyamine Adduct

High strength, high toughness. Chemical tank linings, secondary containment, casting, lamination, pipe coatings

Jointmine

9635

359

28

<3

39

80

Polyamine Adduct

Non solvent coating, pebble finish flooring, tank lining, tile grouts.

Jointmine

936

270 ± 20

9,000 ~ 18,000

<5

11

130

Aliphatic Amine Adduct

Low temperature cure, chemical resistance, water-spot resistance, good adhesion at low temperature. Fast setting adhesives.

Jointmine

W-951

330 ± 20

800 ~ 1,600

<5

5 ~ 10

100

Mannich Base

Cure at low temperature, wet surface curing. Damp surface concrete primer, lining and flooring, adhesives

Jointmine

CT-4150

220 ± 20

50 ~ 200

<3

20 ~ 25

@250g

140

Modified Polyamine

Lower degree of water absorption, fast curing & extremely flexible. Vapor-barrier membrane, mastics, flexibilizing coatings.

Jointmine

CT-4176

167

1,612

<3

60

@250g

250

Polyamine Adduct

Vapor-barrier membrane, crack-bridging membranes.

Jointmine

D-38

1100 ± 20

50 ~ 100

<12

10 ~ 20

34

Modified Aliphatic Amine

High strength & modulus. Heat resistance. Good resistance to mineral acids, aqueous alkali solution, water & aromatic hydrocarbons. Gasohol, ethanol and oxidizing acid resistance. Fast cure plastic & metal adhesive, tooling gel coats, patch repair compounds, steel anchors

Jointmine

D-48

800 ± 30

2,000 ~ 4,000

<5

15

40

Aliphatic Amine Adduct

Construction adhesives, tank linings, high solid coatings, accelerator for amine cure compound

Jointmine

D-50

780 ± 30

60 ~ 150

<8

5

42

Modified Aliphatic Amine

Good resistance to chemical & hot water. Adhesives, patch repair compounds, steel anchors, accelerator for amine cure compound
Products Amine Value
(mg KOH/g)		 Viscosity
(25°C, cPs) 1)		 Color
(Gardner)		 Pot life
(mins) 2)		 AHEW Type Properties / Applications

Jointmine

D-1044

360 ± 20

3,000 ~ 5,000

<5

32

95

Aliphatic Amine Adduct

High strength & modulus, good adhesion properties. Concrete adhesive, epoxy compound, concrete repair

Jointmine

D-1900

810 ± 30

2,500 ~ 5,000

<5

13

40

Aliphatic Amine Adduct

Tank holding chemical, fuel, solvent, alcohol beverage, pipe coating, ship tanks

Jointmine

D-5200

760 ± 30

4,000 ~ 8,000

<5

15 ~ 25

47

Aliphatic Amine Adduct

Rapid cure, water-washable, rigidity & high physical strength, good chemical & boiling water resistance. Colorless coating, civil engineering & adhesives, patch repair kits, gel coats

Jointmine

N-210

530 ± 30

150 ~ 300

<3

10

95

Modified Aliphatic Amine

Low viscosity, some degree of flexibility & toughness, resistance to water & alkali solution, resistance to thermal shock. Patching compound, repair mortars, fast-setting adhesives, putties, tar epoxy system

Jointmine

N-210-2

474

198

1

9

95

Modified Polyamine

Patching compound, repair mortars, fast-setting adhesives, putties, tar epoxy system

Jointmine

N-515

210 ± 20

5,000 ~ 9,000

<3

<9

180

Modified Aliphatic Amine

Low modulus & high flexibility, moisture insensitive, light color, rapid cure.  Fast cure adhesives, gap-filling compounds, resin mortars

Jointmine

N-525

230 ± 20

4,000 ~ 8,000

<4

<8

190

Modified Aliphatic Amine

Resiliency & flexibility, resistance to thermal & mechanical shock, resistance to blushing, accelerator for other hardeners. Fast cure adhesives, gap-filling compounds, resin mortars

Jointmine

N-542

310 ± 20

800 ~ 1,600

<3

4 ~ 6

122

Modified Aliphatic Amine

Fast cure adhesives, gap-filling compounds, resin mortars

Jointmine

5500

710 ± 30

150 ~ 300

<5

15

48

Aliphatic Amine Adduct

Alcohol beverages, chemical tank coatings, concrete repairs, repair mortars.

Jointmine

5569

730 ± 30

350 ~ 700

<5

25 ~ 30

40

Aliphatic Amine Adduct

Chemical resistance, good mechanical properties. Adhesives, electrical potting, tooling, wet lay-up laminating

Jointmine

TD-2000

675 ± 20

1,500 ~ 3,000

<6

78

30

Modified Polyamine

Heat resistance, good toughness, chemical resistance. Heat resistant coatings, castings, laminates, fiber binders, structural adhesives

Jointmine

334-1

300 ± 20

200 ~ 500

<8

30 ~ 40

95

Modified Polyamine

Good surface properties, low degree of sensitivity to atmospheric humidity, high compressive strength, no amine blush. Damp surface primer, resin mortar, solvent-free flooring & adhesives.

Jointmine

8837

420 ± 20

1,500 ~ 3,000

<5

25

64

Mannich Base

Good mechanical properties, good adhesion on concrete & steel, good color stability. Heavy-duty anti-corrosion coatings, flooring compound, secondary containment linings

Jointmine

9044

150 ± 20

8,000 ~ 16,000

<2

3 ~ 5

190

Modified Polymercaptan

Suitable for bonding metals, ceramic, wood & glass. Bonding metals, ceramic, wood & glass. Consumer patch kits, 5 mins cure adhesives

Jointmine

251

730 ± 30

30 ~ 90

<3

48

@150g

42

Polyamine Adduct

Low viscosity, good mechanical properties. Crack injection, marble coatings.

Jointmine

9153

380 ± 20

100 ~ 300

<4

60 *3

75

Polyamine Adduct

High mechanical properties, impact resistant. Impact resistant coatings, solvent-free coatings, repair compounds.

Jointmine

9154

363

250

6 ~ 7

50 *3

75

Polyamine Adduct

High mechanical properties, high chemical resistance. Good surface properties. Epoxy mortar, chemical resistant coatings.

Jointmine

9192

280 ± 20

150 ~ 350

<3

20

100

Polyamine Adduct

Fast curing, high gloss & clarity, resistant to carbamation. Composites, solvent-free coatings & flooring.

Jointmine

9087

320 ± 20

50 ~ 200

<3

70 ~ 80

100

Polyamine Adduct

Solvent-free coatings, architectural & maintenance coatings, pipe & tank lining
Products Amine Value
(mg KOH/g)		 Viscosity
(25°C, cPs) 1)		 Color
(Gardner)		 Pot life
(mins) 2)		 AHEW Type Properties / Applications

Jointmine

9088

290 ± 20

100 ~ 300

<5

30 ~ 40

95

Polyamine Adduct

Solvent-free coatings, architectural & maintenance coatings, pipe & tank lining

Jointmine

9089

290 ± 20

100 ~ 300

<3

30 ~ 40

100

Polyamine Adduct

Solvent-free coatings, architectural & maintenance coatings, pipe & tank lining

Jointmine

9856

470

2,570

2

10 ~ 11 *3

75

Mannich Base

Low temperature cure, rapid development of hardness, good chemical resistance, low exudation. Concrete repair, tank lining.

Jointmine

9606

337

204

<3

50 ~ 60

95

Aliphatic Amine Adduct

Low color, low viscosity, moderate reactivity, good toughness. Water-wipeable tile grout.
Products Amine Value
(mg KOH/g)		 Viscosity
(25°C, cPs) 1)		 Color
(Gardner)		 AHEW Mix Ratio*
4		 Type Solid Content
%		 Properties / Applications

Jointmine

E-501

90 ± 20

900 ~ 2,000

<5

380

48 ~ 77

In-situ EDA Adduct in Xylene/IBA

45 ± 2

Chemical resistance, low free amine. Coal tar epoxy coating, chemical tank lining, primers, maintenance coatings

Jointmine

E-501P

100 ± 20

1,500 ~ 3,000

<5

380

48 ~ 77

In-situ EDA Adduct in PGME

53 ± 2

Chemical resistance, low free amine. Coal tar epoxy coating, chemical tank lining, primers, maintenance coatings

Jointmine

D-1000

130 ± 20

800 ~ 1,600

<8

300

38 ~ 60

Aliphatic Amine Adduct in Xylene/n-butanol

50 ± 2

High flexibility, fast dry. Steel & concrete surface coating, marine & protective coatings, industrial maintenance primers, tank coatings

Jointmine

430

250 ± 20

250 ~ 500

<18

150

20 ~ 31

Mannich Base in Solvesso

70 ± 2

Recoatability, rapid drying, reduced surface tackiness  & surface tolerance coatings
1 Viscosity, cps measured by RVF type Brookfield viscometer.
2 Pot life in 100g mass at 25°C, minutes
3 Gel Time in 150g mass at 25°C, minutes
4 With standard Bisphenol A solid epoxy, EEW 450 ~ 575, e.g. DOW’s DER 661 resin
